American Barns

American Barn

Specification

  • Exterior Walls are clad in ex. 19mm pressure treated shiplap on 75mm x47mm softwood framework (baseplate is pressure treated) and lined internally to 1220mm with 18mm moisture resistant particle board to P5 standard. An option of lining to eaves height is offered
  • Internal front walls are as external walls with a 1200mm grill section
  • Division walls are 47mmx 75mm softwood framework (baseplate is pressure treated)lined one side to eaves height and to 1220mm the other with 18mm moisture resistant particle board to P5 standard.
  • Doors to stables are hinged bottom only . They are ledged and braced with treated TGV boarding to outside and WBP plwood to inside ,a metal anti chew strip is fitted to top edge of door (overall thickness 63mm) all ironmongery is galvanized.
  • Doors to end of building (one end only) .They are hinge hung and made from ledged and bracing with TGV boarding to outside and WBP plywood to inside. All ironmongery is galvanized : Alternatively we can fit a top hung sliding door, manufactured the same as a hinged door.
  • Roofing is corrugated cement fibre sheeting with reinforcing to the latest EU guidelines (30 year guarantee on sheeting). The traditional ‘big six’ profile is fitted to a purlin style roof. This sheeting is available in various colours to suit your surrounding environment. The profile of this sheeting allows full ventilation to all eaves and ridges. We fit one grp translucent sheet per loosebox.
  • Guttering is included to long sides of building
  • Alternative roofing
    : 40mm insulated box section composite metal sheet
    : Onduline roofing is also available
    All sections are bolted and nailed together. All units are bolted to baseworks.
    Approximate dimensions (including brick plinth): Wall height 2.265m. Ridge height 3.650m. Door opening height 2.160m.

American Barn Prices

7.2m   x 10.2m (4 box unit) (24′  x  32′) £  9,000.00
10.8m x 10.2m (6 box unit) (36′  x  32′) £13,000.00
14.4m x 10.2m (8box unit) (48′  x  32′) £16,750.00
Additional Bay
3.6m x 10.2m(2 extra boxes) (12′ x 32′) £  4,000.00

EXTRAS

Full Anti chew strip to door opening £100.00 Each
Line to eaves height with kickboard loose box £170.00 Per box  unit
Front overhang to approximately 950mm Poa
Sliding doors to end £650.00 per set
Top Rear door £150.00 Each
Onduline Roofing Poa
Composite insulated Roofing Poa

All prices are subject to VAT and delivery July 2017
